HeLa Epithelial Cell Tubulin

YFP Bandpass Emission (Narrow Bandwidth Excitation) Blue-Green Set

Fluorescence emission intensity from a culture of human cervical carcinoma epithelial (HeLaline) cells that were transfected with a pEYFP-Tubulin plasmid subcellular localization vector. Cells were transiently transfected and cultured in nutrient medium for a minimum of 24 hours before recording images. The enhanced yellow fluorescent protein gene used in these studies contains several important amino acid substitutions that shift the emission maximum of green fluorescent protein (GFP) by approximately 18 nanometers, from 509 to 527 nanometers. However, the fluorescence emission still appears green when observed in the microscope eyepieces. Note the relatively constant level of green fluorescence and fine detail defining the individual microtubule networks in this cluster of cells.
